Controles de cesto 100% hidráulicos para garantir a máxima confiabilidade e permitir grande precisão nos movimentos.
• Para uma vida útil mais longa e garantida do sistema hidráulico, todos os controles comutáveis pelo cesto e todas as mangueiras hidráulicas posicionadas dentro das lanças que chegam ao distribuidor na torre trabalham em baixa pressão de 25 Bar.
• Controles de emergência do solo.
• Os controles totalmente hidráulicos permitem 2 movimentos simultâneos e proporcionam mais sensibilidade nas manobras progressivas e graduais em relação aos controles eletro-hidráulicos. Os controles totalmente hidráulicos estão livres de qualquer dano aos componentes elétricos causados por tempo chuvoso, umidade, uso frequente, etc.
– As válvulas de bloqueio são montadas diretamente em cada cilindro hidráulico.
• Controla alavancas com retorno automático em posição de repouso. Os movimentos de toda a plataforma são ativados por alavancas, respectivamente posicionadas nos seguintes painéis de controle:
– cesto: placa
de controle da plataforma – torre: placa de controle da plataforma apenas
para emergência – subchassi: placa de controle dos estabilizadores

• Proportional electro-hydraulic basket controls in order to grant the maximum reliability and to allow great accuracy in movements.
• For a longer and guaranteed service life of the hydraulic system all the switchable controls by the basket and all the hydraulic hoses positioned inside the booms that reach the distributor in the turret work in low pressure 25 Bar.
• Emergency controls from the ground.
• The fully hydraulic controls allow more simultaneous movements and provide more sensitivity in progressive and gradual maneuvers with respect to the electro-hydraulic controls. Fully hydraulic controls are free of any damage to electrical components caused by rainy weather, humidity, frequent use, etc.
• The stop valves are directly mounted on each hydraulic cylinder.
• Sensors of load and position are installed and allow to work safely in all the working area
• Controls levers with automatic return in rest position. The movements of the whole platform are activated by levers, respectively positioned in the following controls panels:
– basket: aerial platform control board
– turret: aerial platform control board for emergency only
– subframe: outriggers control board

• Interlock outriggers-boom: Outriggers block when the boom is not in rest position + Boom block when outriggers are not completely stabilised.
• Boom and outriggers block when the PTO in the cab is not engaged.
• LOAD SENSING DEVICE
• Emergency hand pump allows every movement in case the main pump is damaged; it allows the return of the boom and outriggers in rest position.
• All movements are obtained through hydraulic double-acting jacks with double effect safety valves checking both the oil inlet and outlet from the cylinder.
• Removable Magnetic yellow flashing beacon to be positioned on the top of the vehicle cab.
• Warning light indicating that the outriggers are not completely stabilised.
• General emergency stop push-button (basket and ground).
• Thermal protective device for the electric system.
• Safety device to prevent the starter connection if the engine is on.
• Boom-cab anti-collision system (buzzer and stop).

• No.4 IN-SHAPE outriggers with individual controls
• Proportional electro-hydraulic movement controls independent and separate to perfectly level the machine even on
uneven ground
• Hydraulic distributor made of No.4 levers to simultaneously or individually open / close the outriggers
• Consent warning lights for outriggers
• Warning lights for the proper closing of the outriggers to safely drive on the road

• PTO AND HYDRAULIC PUMP GEAR TYPE
• Warning light inside the cab to indicate PTO on
• Hour counter in the cab to check the working hours and the frequency of the scheduled tests
